| MLA PART CODE | SFPLBB |
|---|---|
| DESCRIPTION | Screwless 230V LED Plinth Light - Brushed Brass |
| NET WEIGHT (KG) | 0.151 |
| FINISH | Brushed Brass |
| LIGHT REFLECTANCE VALUE | 73~77 |
| CONSTRUCTION | Construction - 201 Stainless steel |
| CLASS | I |
| IP RATING | IP20 |
| INPUT VOLTAGE | 230V 50Hz |
| DIMENSIONS (MM) | Height - 87.5 Width - 87.5 Depth - 25.2 Projection - 4.5 Recessed Depth - 20.7 |
| MINIMUM MOUNTING BOX DEPTH | 25-35mm (dependent on wiring conditions) |
| DIFFUSER | Opal |
| WATTAGE (W) | 0.8 |
| LAMP TECHNOLOGY | SMD LED |
| LAMP INCLUDED | Yes |
| LUMENS (LM) | 15 |
| LUMEN TOLERANCE | 5% |
| EFFICACY LIGHT SOURCE (LM/W) | 19 |
| CCT | 4000K |
| LIGHT COLOUR | Cool White |
| CRI | ≥80 |
| SDCM | ≤6 |
| RUNNING CURRENT (A) | 0.01 |
| LIFE SPAN (HRS) | 50,000 |
| DIMMABLE | No |
| EARTH TERMINAL | Yes |
| TERMINAL CAPACITY | 2 x 1.0mm² or 2 x 1.5mm² |
| WARRANTY | 2year(s) |
| MANUFACTURED IN ACCORDANCE WITH | BS EN 60598 |
| ORIGIN OF MANUFACTURE | China |
| DECLARATION OF CONFORMITY (HELD ON FILE) | Yes |
| EAN | 5061061278055 |
