DATASHEET
ATCW15W
Atlas Pro 230V 3-Circuit Track Dimmable Spotlight in Matt Black - 10/12/15W and CCT Adjustable
| MLA PART CODE | ATCW15W |
|---|---|
| DESCRIPTION | Atlas Pro 230V 3-Circuit Track Dimmable Spotlight in Matt Black - 10/12/15W and CCT Adjustable |
| NET WEIGHT (KG) | 0.5 |
| FINISH | Matt White |
| DIFFUSER | Frosted |
| DIMENSIONS (MM) | Diameter - 60 Length - 145 Overall Height - 214 |
| TILT (DEGREES) | 80 |
| ROTATION (DEGREES) | 350 |
| CONSTRUCTION | Construction - Aluminium Construction 2 - & glass |
| CLASS | II |
| IP RATING | IP20 |
| WATTAGE (W) | 10 / 12 / 15 |
| LAMP TECHNOLOGY | CoB LED |
| LAMP INCLUDED | Yes |
| LUMENS (LM) | 940/1085/1120/1120/1265/1290/1295/1465/1475 |
| LUMENS LIGHT SOURCE ONLY (LM) | 1565 |
| LUMEN TOLERANCE | 5% |
| EFFICACY (LM/W) | 134 |
| CIRCUIT WATTAGE (W) | 11.65 |
| CCT | 2700/4000/6000K |
| LIGHT COLOUR | CCT |
| CRI | >90 |
| SDCM | <6 |
| RUNNING CURRENT (A) | 0.351 |
| SVM | 0.007 |
| PST-LM | 0.69 |
| BEAM ANGLE (DEGREES) | 47 |
| L70B50 LIFESPAN (HRS) | 50,000 |
| LED COMPATIBLE | Yes |
| DIMMABLE | Yes* |
| INPUT VOLTAGE | 230V 50Hz |
| WARRANTY | 5year(s) |
| ORIGIN OF MANUFACTURE | China |
| DECLARATION OF CONFORMITY (HELD ON FILE) | Yes |
| EAN | 5061061278260 |
Date Created: 09/01/2026 13:47
