DATASHEET
| MLA PART CODE | M1100TB |
|---|---|
| DESCRIPTION | Metalclad 10A Fan Isolator Switch - Textured Sand Black Finish |
| NET WEIGHT (KG) | 0.1965 |
| FINISH | Textured Sand Black |
| DIMENSIONS (MM) | Height - 81.2 Width - 81.2 Depth - 48.4 |
| CONSTRUCTION | Construction - SPCC Steel |
| CLASS | I |
| IP RATING | IP20 |
| INPUT VOLTAGE | 230V 50Hz |
| SWITCH TYPE | Triple Pole |
| SWITCH FUNCTION | Fan Isolator |
| EARTH TERMINAL | Yes |
| LOAD/MAX. LOAD | 10A |
| TERMINAL CAPACITY | 2 x 1.0mm² or 2 x 1.5mm² |
| ADDITIONAL FEATURES | Metal Matt Black Rocker |
| WARRANTY | 25year(s) |
| ORIGIN OF MANUFACTURE | China |
| DECLARATION OF CONFORMITY (HELD ON FILE) | Yes |
| EAN | 5056270888775 |
Date Created: 21/11/2025 13:26
