Type A RCD for AC residual current and pulsating DC up to 6 mA. Suitable for equipment with electronic components such as IT equipment.
Passive (latching) type, which will automatically reset after a power outage, without the need for manual resetting.
- Tripping current (IΔn): 30mA
- Trip time @ IΔn: 40ms
- Minimum mounting box depth: 35mm
- Double pole RCD contact break
| Unit Barcode | 5056270811537 |
|---|---|
| Inner Carton Quantity | 10 |
| Inner Carton Weight | 1.167 Kg |
| Inner Carton Length | 18.5 cm |
| Inner Carton Width | 14.2 cm |
| Inner Carton Height | 9.3 cm |
| Inner Carton Barcode | 5056270811544 |
| Outer Carton Quantity | 100 |
| Outer Carton Weight | 12.20 Kg |
| Outer Carton Length | 48.5 cm |
| Outer Carton Width | 29.5 cm |
| Outer Carton Height | 20 cm |
| Outer Carton Volume | 0.028600 m3 |
| Outer Carton Barcode | 5056270811551 |
| Height | 86 mm |
|---|---|
| Width | 86 mm |
| Depth | 40.2 mm |
| Projection | 15.4 mm |
| Recessed Depth | 24.8 mm |
| Min. Mounting Box Depth | 35mm |
| Plate Depth | 12.5 mm |
| Construction | Thermoset resin |
|---|---|
| Finish | White |
| IP Rating | IP20 |
| Primary Voltage | 230V 50Hz |
| Earth Terminal | Yes |
|---|---|
| Terminal | Captive |
| RCD functionality | 30mA Type-A latching |
| Warranty | 2 |
|---|
| Line Drawing 1 |  |
|---|
| Commodity Code | 8536301000 |
|---|
